XEON Computer Motherboard Lga2011 2 Ram C612 Chipset X99-P3X-V1.0 TPM Supported

Product Categories

Shenzhen kaiente industry Co.Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Model Number : X99-P3X-V1.0

Model Name : X99-P3X-V1.0

Chipset : C612

CPU : Intel Xeon E5 LGA2011-V3 pin CPU (with DDR3 memory controller), E5-2629v3/2666v3/2673v3/2676v3/2678v3/2696v3/2684v4/2696v4, etc.

network : 1*RJ45 interface

memory : 2*DDR3 DIMM, dual-channel design, supports 1033/1333/1600/1866MHz(MAX), and supports up to 64G (32G*2).

TPM : 1*14 PIN pin (supporting MSI 14PIN TPM module)

PCIE : PCIE1 :PCIE X16 3.0 slot (from CPU) PCIE2 :PCIE X1 2.0 slot (from PCH)

product size : 170 x 216mm, 4-layer PCB

Packaging Details : Carton box

Delivery Time : 5-8 working Days

Supply Ability : 10000pcs/Day

MQO : 20

Contact Now

XEON Mother board lga2011 2 ram cheap C612 chipset X99-P3X-V1.0 TPM supported

l Processor supporting Intel Xeon E5 LGA2011-V3 pin

l Support dual-channel DDR3*2 memory

l 1 M.2 (NVME/SATA protocol; Cap-hopping switch)

l Support 3* SATA interface

l The rear IO provides 6 USB2.0 interfaces and 2 USB3.0 interfaces.

l The built-in pin can expand 2 USB2.0 interfaces and 2 USB3.0 interfaces.

l 1 x Gigabit network card, supporting PXE and network wake-up function.

Model Name	X99-P3X V1.0
Motherboard chip	C612
CPU	Intel Xeon E5 LGA2011-V3 pin CPU (with DDR3 memory controller)
	For example: E5-2629v3/2666v3/2673v3/2676v3/2678v3/2696v3/2684v4/2696v4, etc.
memory	2DDR3 DIMM, dual-channel design, supports 1033/1333/1600/1866MHz(MAX), and supports up to 64G (32G2).
Cunzhu	1M.2 slot (NVME:PCIE 3.0 X4/SATA protocol, cap-jumping switching); 3SATA interface (SATA3.0)
Display interface	/
network	1*RJ45 interface
Network card chip	RTL8111H gigabit network card chip
TPM	1*14 PIN pin (supporting MSI 14PIN TPM module)
audio frequency	1Line out,1MIC In,1Line in； 1F_Audio built-in pin
Audio chip	Realtek ALC 887/897 HD audio chip
Usb interface	IO interface: 6USB2.0; 2USB3.0 Built-in pins: 1 set of USB2.0 pins (2 USB2.0 ports can be extended); 1 set of USB3.0 pins (2 USB3.0 ports can be expanded)
PCIE	PCIE1 :PCIE X16 3.0 slot (from CPU) PCIE2 :PCIE X1 2.0 slot (from PCH)
Functional pin	1FPANEL panel pin; 14Pin CPU fan; 13Pin SYS fan; 1JBAT pin; 1*JLPC pin
Power input	24Pin+8Pin ATX power socket
product size	170 x 216mm, 4-layer PCB
